| Order # | 6800010 | 6800020 | 6800030 |
| Model | G10 | G20 | G30 |
| Power supply | 220V，50/60Hz | 220V，50/60Hz | 220V，50/60Hz |
| Vessel capacity | 10L | 20L | 30L |
| Glass material | High borosilicate glass GG-17 | High borosilicate glass GG-17 | High borosilicate glass GG-17 |
| Stand material | SS304 | SS304 | SS304 |
| Vessel cover material | High borosilicate glass GG-17 | High borosilicate glass GG-17 | High borosilicate glass GG-17 |
| Vessel cover diameter | 265mm | 265mm | 265mm |
| Cover ports | 7 | 7 | 7 |
| Mixer motor power | 120W | 120W | 180W |
| Speed adjustment type | Frequency control | Frequency control | Frequency control |
| Rotation speed range | 50~400rpm | 50~400rpm | 50~400rpm |
| Temperature range | -60~200℃ | -60~200℃ | -60~200℃ |
| Digital display | Rotation speed, medium temperature | Rotation speed, medium temperature | Rotation speed, medium temperature |
| Type of seal | Mechanical seal | Mechanical seal | Mechanical seal |
| Maximum vacuum | < 20mbar | < 20mbar | < 20mbar |
| Material of mixer shaft | SS304 coated with PTFE | SS304 coated with PTFE | SS304 coated with PTFE |
| Type of agitator | Screw type | Screw type | Screw type |
| Type of temperature meter | PT100 digital | PT100 digital | PT100 digital |
| Vacuum meter | Indicator | Indicator | Indicator |
| Discharging valve | Bottom discharge with PTFE | Bottom discharge with PTFE | Bottom discharge with PTFE |
| Outlet | Bottom discharge | Bottom discharge | Bottom discharge |
| Condenser type and heat transfer area of condensation recovery | Double layer screw shape 0.40m2 | Double layer screw shape 0.40m2 | Double layer screw shape 0.40m2 |
| Constant pressure hopper | 500mL | 1000mL | 1000mL |
| Divide bottle | 250mL with valve | 250mL with valve | 250mL with valve |
| Collect bottle | 5L - NS24×2 with bottom valve | 5L - NS24×2 with bottom valve | 5L - NS24×2 with bottom valve |
| Temperature measurement port | NS24 | NS24 | NS24 |
| Liquid medium valve/Air intake valve | NS29 | NS34 | NS34 |
| Condensing port | NS34 | NS34 | NS34 |
| Spare port | F50×2（PH/conductivity meter by customer） | F50×2（PH/conductivity meter by customer） | F50×2（PH/conductivity meter by customer） |
| Solid feeding port | SF110 | SF110 | SF110 |
| Liquid leakage plate | SS316L - removable plate | SS316L - removable plate | SS316L - removable plate |
| Caster | Load bearing brake casters | Load bearing brake casters | Load bearing brake casters |
| Vessel bottom valve O ring | FFKM | FFKM | FFKM |
| Mixing O ring | FFKM | FFKM | FFKM |
| Vessel cover and diverter valve O ring | coated with PTFE | coated with PTFE | coated with PTFE |
| Jacket O ring | FKM | FKM | FKM |
| Other position O ring-blind plate/bottom valve gasket etc | EPDM | EPDM | EPDM |
| Thermal insulation sleeve | Available | Available | Available |
| Overall dimensions | 900×500×1900 | 950×520×1950 | 1000×560×2050 |
