Fisco Pro series

Fisco-Pro is a pilot-scale vacuum emulsification and homogenization system that can operate in a vacuum pressure environment. Different stirring and homogenization system options can be selected depending on the process scenario.

Get a Quote

Product Details

The Fisco-Pro series is a newly launched pilot-scale vacuum emulsification and homogenization system. In line with classic European designs, it enables the dispersion, emulsification, homogenization, and mixing of materials under vacuum or pressure. Highly customizable, it allows for the replacement of different agitators and the configuration of homogenization systems in various forms and methods to suit different material properties and industry characteristics.

Technical Parameter

Basic parameters

ModelFisco 500 proFisco 1000 proFisco 2000 proFisco 3000 proFisco 5000 pro
Ambient temperature5~40℃5~40℃5~40℃5~40℃5~40℃
Relative humidity80%80%80%80%80%
Working temperature rangeCustomized according to URS
Working pressure rangeCustomized according to URS
Handleable material viscosity range Customized according to URS
Agitator systemCustomized according to URS
Power supply380V/50Hz380V/50Hz380V/50Hz380V/50Hz380V/50Hz
Footprint (mm)1500x1500x30001800x1800x38002000x2000x42002300x2300x48003000x3000x5300
Weight (Kg)20003000400060009000
Reactor port Customized according to URS
Surface treatmentMachining surface, mechanical polishing, Electropolishing
Material of wetted parts   Stainless steel (304, 316L, 316Ti, 904L, 2205, 2507, etc.), carbon steel, titanium alloy, zirconium alloy, Hastelloy alloy,fluoropolymer lining, spray coating, etc.
Control systemPLC control, standard configuration includes monitoring of temperature, pressure, liquid level, etc.
Cleaning wayIt features built-in CIP functionality (not available in internal circulation homogenization systems), and its structural design meets SIP/CIP requirements.

Optional Homogenization Systems

ModelFisco 500 proFisco 1000 proFisco 2000 proFisco 3000 proFisco 5000 pro
FSTE Internal and External Dual Circulation Homogenizer
Motor power11-15kW22-37 kW37-55 kW55-75 kW55-75 kW
Top speed3000rpm1500 rpm1500 rpm1500 rpm1500 rpm
Homogenization functionInternal circulation intermittent homogenization within the tank; external circulation homogenization returns to the tank or discharges material, with external circulation providing a 3 kg head.
Powder suctionfunction It has an external interface for connecting to powder and liquid suction tubing
FDE external circulation homogenizer
Motor power11-15kW18.5-22 kW37-45 kW45-55 kW55-75 kW
Top speed3000rpm3000 rpm3000 rpm1500 rpm1500 rpm
Homogenization functionExternal circulation homogenized recharge or discharge
Powder suctionfunction It does not have a powder suction function
FSH Series – Integrated Pumping & Homogenizing High-Efficiency Solution
Motor power7.5-11kW22-37kW45 kW90 kW/
Top speed3000rpm3000 rpm3000 rpm1500 rpm/
Homogenization functionSupports external circulation homogenizing for material return to tank or direct discharge, ensuring more thorough homogenization and flexible discharging.
Powder suction functionEquipped with standard external connections for direct hookup to powder and liquid suction pipelines, delivering excellent expandability.
Pumping functionOffers non-homogenizing pumping mode; materials can be directly returned to the tank or discharged without passing  through the homogenizing chamber to meet various process requirements.
