| Order # | 6821001 | 6822001 | 6823001 |
| Model | Fisco-1S | Fisco-2S | Fisco-5S |
| Power supply | 220V，50Hz | 220V，50Hz | 220V，50Hz |
| Minimum mixing capacity | 300mL | 500mL | 1000mL |
| Minimum emulsifying capacity | 600mL | 1000mL | 2000mL |
| Maximum emulsifying capacity | 1000mL | 2000mL | 5000mL |
| Maximum working temperature | 120℃ | 120℃ | 120℃ |
| Vacuum condition | -0.092MPa | -0.092MPa | -0.092MPa |
| Maximum working viscosity | 100,000cP | 100,000cP | 100,000cP |
| Mixer motor power | 50W | 50W | 50W |
| Mixer speed range | 10-200rpm | 10-200rpm | 10-200rpm |
| Standard mixer agitator | Anchor ribbon agitator with scrapper | Anchor ribbon agitator with scrapper | Anchor ribbon agitator with scrapper |
| Scrapper material | PTFE | PTFE | PTFE |
| Homogenizer motor power | 500W | 500W | 500W |
| Homogenizer speed range | 10000-28000rpm | 10000-28000rpm | 10000-28000rpm |
| Standard homogenizer agitator | 20DG | 20DG | 25DG |
| Openings on cover | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening |
| Lifting height | 300 | 300 | 300 |
| Medium-contact material | SIC, SS316L, borosilicate glass, FKM, PTFE | SIC, SS316L, borosilicate glass, FKM, PTFE | SIC, SS316L, borosilicate glass, FKM, PTFE |
| Outer diameter of vacuum opening | 10 | 10 | 10 |
| Jacket inlet/outlet size | 12 | 12 | 12 |
| Permissible temperature range | 5-40℃ | 5-40℃ | 5-40℃ |
| Permissible humidity range | 80% | 80% | 80% |
| Overall dimensions | 470×420×1200 | 470×420×1200 | 470×420×1200 |
| Weight | ~35kg | ~37kg | ~42kg |
