| Order # | 6831000 | 6832000 | 6835000 |
| Model | Fisco-1SP | Fisco-2SP | Fisco-5SP |
| Power supply | 220V，50Hz | 220V，50Hz | 220V，50Hz |
| Minimum mixing capacity | 300mL | 500mL | 1000mL |
| Minimum emulsifying capacity | 600mL | 1000mL | 2000mL |
| Maximum emulsifying capacity | 1000mL | 2000mL | 5000mL |
| Maximum working temperature | 120℃ | 120℃ | 120℃ |
| Vacuum condition | -0.096MPa | -0.096MPa | -0.096MPa |
| Maximum working viscosity | 100,000cP(appropriately increased according to demand) | 100,000cP(appropriately increased according to demand) | 100,000cP(appropriately increased according to demand) |
| Mixer motor power | 220W | 220W | 220W |
| Mixer speed range | 8-330rpm | 8-330rpm | 8-330rpm |
| Standard mixer agitator | Anchor ribbon agitator with scrapper | Anchor ribbon agitator with scrapper | Anchor ribbon agitator with scrapper |
| Scrapper material | PTFE | PTFE | PTFE |
| Homogenizer motor power | 650W | 650W | 650W |
| Homogenizer speed range | 2000-26000rpm | 2000-26000rpm | 2000-26000rpm |
| Standard homogenizer agitator | S20DG | S20DG | S25DG5S |
| Openings on cover | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening | Homogenizer opening with hopper openingthermometer opening, vacuum opening,3 spare opening |
| Lifting height | 250 | 250 | 300 |
| Medium-contact material | SIC, SS316L, borosilicate glass, FKM, PTFE | SIC, SS316L, borosilicate glass, FKM, PTFE | SIC, SS316L, borosilicate glass, FKM, PTFE |
| Outer diameter of vacuum opening | 10 | 10 | 10 |
| Jacket inlet/outlet size | 12 | 12 | 12 |
| Permissible temperature range | 5-40℃ | 5-40℃ | 5-40℃ |
| Permissible humidity range | 80% | 80% | 80% |
| Overall dimensions | 470×420×1200 | 470×420×1200 | 470×420×1200 |
| Weight | ~35kg | ~37kg | ~42kg |
